Capacity volume for water, l

from 0 to 9000

Capacity volume for frother, l

540 (other as per customer request)

Overall dimensions (length / height / width), mm

9680х3100х2500

Full mass, kg

20570

Colorography schemes

GOST R 50574-2002 (other as per customer request)

Cab fire truck, the number of places for firefighting crew (including the driver's seat)

all-metal standard chassis cabin, two-door, single-row, three places

Execution option of loading space of the fire truck

water tank, foam tank, fire pump, water and foam communications,

body superstructure with compartments for fire-technical equipment and rescue equipment

Fire pump

combiner centrifugal fire pump NZPK-40/100-4/400, (according to GOST R 52283-2004 "Centrifugal fire pumps. General technical requirements. Test methods"), with a spray barrel with a hose reel  SRVDK, rear location (other as per customer request)

Fire pump performance

from 0 to 40 liters per second (or another with another fire pump)

Completeness FTE

according to the standards of the Order of the Ministry of Emergency Situations of Russia №425 of July 25, 2006 (other as per customer request)

Placement FTE

in the compartments, taking into account the tactics of its operational use, to ensure the reliability of equipment fixation, accessibility, convenience and safety during removal and installation

Wheel formula / driving wheels

6 х 6 / all

The layout of the base chassis of a fire truck

engine layout front, longitudinal,

cabin behind engine, loading workspace behind cabin

Wheelbase, mm

4755+1400

Wheel track (front / rear), mm

2040 / 2040

Engine (type, ecological class)

YaMZ-53623-10, four-stroke, diesel, Euro-5

Engine power, hp

275

Maximum speed, km/h

90

Gearbox (type)

mechanical

Tires (type, size)

425/85R21
